Totem Acoustic
TO TRIBE IN-WALL SUB 12"
The Sub 12 is for the room that has to be felt. A single 12-inch Kevlar-honeycomb driver on a 5.25-inch voice coil works against a matched 12-inch passive radiator in the same 96 mm of depth as the Double 8, and reaches 22 Hz — low enough that a film's floor arrives rather than being implied. It asks for a bigger hole, 370 x 690 mm, and it wants an amplifier to itself: unlike the Double 8, one Sub 12 per 500-watt Totem amp, which again ships with it. Same wood-stud rule, same satin white or black grille that takes your wall paint. Choose the Double 8 for a tidy fit; choose this one when the brief says cinema.
Specifications
| Design | Full back-boxed, high-performance loudspeaker. Only 1 Double 12 subwoofer can be connected to a Tribe Amplifier. Must be affixed to wood studs, not aluminum. |
|---|---|
| Woofer | 1 active and 1 passive 12″/ 30.48 cm multi-layer Kevlar honeycomb |
| Frequency response | 22 Hz – 200 Hz |
| Recommended power | Supplied 500 W external Totem amplifier |
| Speaker terminals | gold plated 5 way banana plugs |
| Phase | 0° – 180° continuously variable |
| Low-pass filter | variable from 40Hz – 120Hz, Bypass when turned completely to the right |
| Amplifier power | 500 watts |
| Analog inputs | 1 Pair RCA |
| Outputs | 1 Pair RCA |
| Subwoofer output | 1 Pair Binding Posts |
| Volume control | Adjusts Input Signal Level/Volume |
| Controls | Logo Power Indicator: Red in standby and Blue when active, fading after 30 seconds | Power Switch | Model Select Switch: Tribe In-wall Sub 8 – select SUB8, Tribe In-wall Sub 12 – select SUB12 |
| Power modes | On/Auto Switch |
| THD | <0.1% @ Maximum Rated Output Frequency response: 20Hz – 200Hz Input Impedance: >20 kΩ |
| Mains connection | Connector: 100-120 V / 220-230 V – Auto Sensing | Fuse holder: T5AL, 250 Volt |
| Cutout | 14.57″ x 27.16″ / 370 x 690mm |
| Grille | magnetic, paintable, virtually bezel-less white metal (grills may be painted to match your decor) Amplifier and rack ears included |
| Dimensions | Sub: 16.85″ x 28.27″ x 3.78″ / 428 x 718 x 96mm | Amplifier incl. feet: 17” x 2.25” x 14” / 43.18 x 5.715 x 35.56 cm |
| Width | 19” / 48.26 cm |
| Weight | Sub: 22lb / 9.98kg | Amplifier net: 6.8 kg (15 lbs.) |
| Finishes | Satin White | Satin Black |
