Totem Acoustic
TO KIN IC82 UNIT
The IC82 is the IC62's bigger brother, and the one to specify when the room is large or the ceiling is high. An 8-inch MHEX woofer takes the bottom end down to 38 Hz, sensitivity up to 91 dB, and it will swallow 150 watts. What the installer needs to know is that the extra output costs space: a 246 mm cutout and roughly 170 mm of depth above the ceiling, against 211 mm and 121 mm for the IC62. Everything else is shared — the pivoting ceramic tweeter, the low-volume intelligibility switch, stainless weather-resistant hardware, the paintable magnetic grille. Two IC82s will carry a big open kitchen that four smaller speakers would only decorate.
Specifications
| Design | 8″ In-Ceiling with LVI equalization switch |
|---|---|
| Woofer | 8” MHEX Phenolic Honeycomb Woven Hybrid woofer in die-cast basket |
| Tweeter | 1” Ceramic coated aluminum dome tweeter |
| Frequency response | 38 Hz – 30 kHz |
| Impedance | 8 Ohm |
| Sensitivity | 91dB |
| Recommended power | 20-150 W |
| Speaker terminals | Spring loaded Gold Plated |
| Cutout | 246.25mm |
| Grille | magnetic, paintable, virtually bezel-less white metal |
| Dimensions | 271 x 169.55mm |
| Weight | 5.65lb / 2.56kg |
| Accessories & options | Pre-construction brackets, square grilles, acoustic back can |
