Totem Acoustic
TO KIN SUB10 - BLACK
Where the Sub 8 is ported, the Sub 10 is sealed — and that changes its character more than the extra inch does. The trapped air damps the cone, so bass starts and stops cleanly and the cabinet can stand close to a wall, or inside furniture, without turning boomy. A 10-inch spun-fibreglass cone on an oversized vented magnet, 300 watts of Class D, and a response to 27 Hz. Bass EQ switches between Natural, which stays linear, and High Impact when a film asks for it. Crossover 50 to 150 Hz, variable phase and level. A wireless receiver is built in: add the Link transmitter and this subwoofer needs a power socket and nothing else.
Specifications
| Design | Design: Powered Subwoofer | Enclosure: Sealed |
|---|---|
| Woofer | 10” cone composed of high tensile spun fibreglass strands top coated and bonded to a cellulose core. Driven by vented magnetics utilizing an oversized ferrite magnet assembly. Butyl rubber surround. |
| Frequency response | 27 Hz – 200 Hz |
| Crossover frequency | Variable from 50Hz to 150Hz, 24dB/Octave |
| Voice coil | High temperature enamel resin coated copper wire wound on a vented aluminum former |
| Phase | Variable from 0 to 180 degrees |
| Amplifier | Class D 300 watts |
| Inputs | Stereo RCA/LFE/Wireless |
| Volume control | Variable |
| Power modes | Auto/On |
| Dimensions | 13” x 11.5” x 13.5” / 330mm x 292mm x D 345mm |
| Weight | 30.86lb / 14kg |
| Finishes | Satin White | Satin Black |
